USB Magnetic Stripe Reader & Encoder for passbook - MSRC4777

Basic Information
Place of Origin: China
Brand Name: OEM / Customize
Certification: ROHS
Model Number: MSRC4777
Minimum Order Quantity: 1 unit, sample avaliable
Price: By inquiry
Packaging Details: 15 units / Carton
Delivery Time: 0-4 weeks according to quantities
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000+ units / month
Detail Information
Name: Magnetic Stripe Reader & Encoder Interface: USB (Virtual COM Port )
Support Card: Magnetic Stripe Card / Passbook Read & Write Color: Black / Grey White
Power Supply: USB Compatibility: IBM4777
High Light:

ic card reader

,

ic chip reader


Product Description

Product: USB Magnetic Stripe Reader & Encoder / Magnetic Stripe Reader & Writer

   USB Magnetic Stripe Reader & Encoder for passbook - MSRC4777 0USB Magnetic Stripe Reader & Encoder for passbook - MSRC4777 1USB Magnetic Stripe Reader & Encoder for passbook - MSRC4777 2

Model: MSRC4777





1. Product Summarization
MSRC4777 magnetic strip reader and encoder (MSRE) and MSRC4778 encrypting Pinpad are
completely compatible to IBM4777 and IBM4778, specially added the function of sound prompt.


MSRC4777 MSRE is special to develop for bank using to read and encode magnetic stripe, such
as passbook, credit card, debit card and operate card, it can take place of the IBM4777. The interface
has USB(virtual COM port) , PS/2 or RS232 in option, compatible with IBM4777, support the CT/LANDP

system of IBM.


MSRC4777 MSRE is easily to use, performance stabilization, is a perfect choice worked in CT/LANDP.


MSRC4778 Pinpad is compatible to IBM4778, assorted to varies POS and Terminal to input the
password, assured the security dealing.


2. MSRC4777 Specifications
Working environment: Temperature 0℃~45℃, humidity 20%~90%RH, no condensation
Power:DC+5V, 300mA
Cubage :215mm×64mm×65mm
Weight :700g
Interface :PS/2 or RS232,accommodate-self
Data Standard:ISO/IBM
Pull speed:10cm/s~100cm/s
Magnetic head life:500,000 times



3. MSRC4778 (Matched Pinpad)
Working environment: Temperature 0℃~45℃, humidity 20%~90%RH, no condensation
Power :DC+5V, 300mA
Cubage :148mm×108mm×85mm
Weight :300g
Interface :PS/2 or RS232,accommodate-self
Life of key button: 1,000,000 times
LCD display :2*16 characters, with letter or figure
Pad layout: 12 keys, 0-9 figure key, “Enter” key,”Clear” Key
